Solid Carbide End Mills
How to Choose the Correct End Mill
для размещения заказа - zakaz@widiahanita.ru
End Mills
Z = number of teeth
end mill
Z=1
Fine Finishing Finishing Roughing Slot Milling Plunging
Contour
Milling
Peel
Milling
Trochoidal
Milling
end mill
Z=2
end mill
Z=3
end mill
Z = 4/5
multi-flute cutter
Z = 6-8
Ball Nose and Torus End Mills
ball nose end mill
Z=2
ball nose end mill
Z=4
*VariMill™/VariMill™ GP Only
*
first choice
suitable with limitations
not recommended
Always select a tool with the shortest possible flute length whenever possible.
This will increase the stability of the tool and give the best results.
When selecting an end mill, the following machining factors will affect
your selection of the correct end mill for your application:
1. Tool overhang.
2. Coolant flow.
3. Machine and setup stability.
4. Machine power and torque.
5. Material to be machined.
6. Machine adaptor size (CV40, CV50, HSK63, etc.).
7. See Tool Reference Guides on pages N6–N15.
N2
