WIDIA™ Victory™
Catalogue Numbering System
для размещения заказа - zakaz@widiahanita.ru
How do the new Victory Catalogue numbers work?
Each character in our catalogue number signifies a specific trait
of that product. Use the following key columns and corresponding
images to easily identify which attributes apply.
OLD Grade Nomenclature • Metric
Series Number
5 77
7
Series
5 = 5-Flute Carbide
4 = 4-Flute Carbide
250
Cutting
Diameter
010 = 1mm
020 = 2mm
030 = 3mm
040 = 4mm
050 = 5mm
060 = 6mm
070 = 7mm
080 = 8mm
090 = 9mm
100 = 10mm
120 = 12mm
140 = 14mm
160 = 16mm
180 = 18mm
200 = 20mm
250 = 25mm
320 = 32mm
NEW Victory Nomenclature • Metric
Series Number
577 C
Series
Special
Designation
250
Cutting
Diameter
0
Corner
Condition
8
Shank
Diameter
W
Shank
Style
5 = 5-Flute Carbide
4 = 4-Flute Carbide
N20
C = Centre Cutting
010 = 1mm
020 = 2mm
030 = 3mm
040 = 4mm
050 = 5mm
060 = 6mm
070 = 7mm
080 = 8mm
090 = 9mm
100 = 10mm
120 = 12mm
140 = 14mm
160 = 16mm
180 = 18mm
200 = 20mm
250 = 25mm
320 = 32mm
0 & Z = Sharp
1 = 0,75
2 = 0,50
3 = 1,00
4 = 1,50
5 = 2,00
6 = 2,50
7 = 3,00
8 = 4,00
zakaz@widiahanita.ru
www.widiahanita.ru
2 = 6mm
3 = 8mm
4 = 10mm
5 = 12mm
6 = 16mm
7 = 20mm
8 = 25mm
9 = 32mm
T = Plain
W = Weldon®
V = SAFE-hOCK®
