High-Performance Solid Carbide End Mills • VariMill™
Series 4717 • VariMill I™ • Extended Length of Cut
• Unequal flute spacing.
• Centre cutting.
• Standard items listed. Additional
styles and coatings made-to-order.
Series 4717 • VariMill • Extended Length of Cut
graTdieATlNiA-LlNW-LW
TiAlN
order #
3641112
3641113
3641114
3641115
3641116
3641117
catalogue #
471706002LW
471708003LW
471710004LW
471712005LW
471716006LW
471720007LW
D1
6,0
8,0
10,0
12,0
16,0
20,0
D
6
8
10
12
16
20
D1
)3
> 3-6
> 6–10
> 10–18
> 18–30
End Mill Tolerances
tolerance e8
-0,014/-0,028
-0,020/-0,038
-0,025/-0,047
-0,032/-0,059
-0,040/-0,073
D
)3
> 3–6
> 6–10
> 10–18
> 18–30
tolerance h6
+/-
0/-0,006
0/-0,008
0/-0,009
0/-0,011
0/-0,013
first choice
alternate choice
length of cut
Ap1 max
32,00
32,00
38,00
51,00
57,00
57,00
length
L
76
87
89
100
125
125
BCH
0,40
0,40
0,50
0,50
0,50
0,50
