High-Performance Solid Carbide End Mills • VariMill™
Application Data • Series 4727 • VariMill I™
Series 4727 • VariMill
Side Milling (A)
Material
Group
Finishing
TiAlN
A Cutting Speed — vc
m/min
ap ae min
max
Roughing
TiAlN
A Cutting Speed — vc
m/min
ap ae min
max
Recommended feed per tooth (fz = mm/th)
for side milling (A).
D1 — Diameter
mm 12,0 16,0 20,0
1 Ap1 max 0,05 x D* 300 – 400 Ap1 max 0,2 x D 150 – 200
fz
0,083
0,101
0,114
2 Ap1 max 0,05 x D* 280 – 380 Ap1 max 0,2 x D 140 – 190
fz
0,083
0,101
0,114
3 Ap1 max 0,05 x D* 240 – 320 Ap1 max 0,2 x D 120 – 160
P
4 Ap1 max 0,05 x D* 180 – 300 Ap1 max 0,2 x D 90 – 150
fz
fz
0,070
0,062
0,087
0,077
0,101
0,088
5 Ap1 max 0,05 x D* 120 – 200 Ap1 max 0,2 x D 60 – 100
fz
0,056
0,070
0,081
6 Ap1 max 0,05 x D* 100 – 150 Ap1 max 0,2 x D 50 – 75
fz
0,047
0,057
0,065
1 Ap1 max 0,05 x D* 180 – 230 Ap1 max 0,2 x D 90 – 115
fz
0,070
0,087
0,101
M 2 Ap1 max 0,05 x D* 120 – 160 Ap1 max 0,2 x D 60 – 80
fz
0,056
0,070
0,081
3 Ap1 max 0,05 x D* 120 – 140 Ap1 max 0,2 x D 60 – 70
fz
0,047
0,057
0,065
1 Ap1 max 0,05 x D* 240 – 300 Ap1 max 0,2 x D 120 – 150
fz
0,083
0,101
0,114
K 2 Ap1 max 0,05 x D* 220 – 260 Ap1 max 0,2 x D 110 – 130
fz
0,070
0,087
0,101
3 Ap1 max 0,05 x D* 200 – 260 Ap1 max 0,2 x D 100 – 130
fz
0,056
0,070
0,081
1 Ap1 max 0,05 x D* 100 – 180 Ap1 max 0,2 x D 50 – 90
fz
0,070
0,087
0,101
2 Ap1 max 0,05 x D* 50 – 80 Ap1 max 0,2 x D 25 – 40
S
3 Ap1 max 0,05 x D* 120 – 160 Ap1 max 0,2 x D 60 – 80
fz
fz
0,070
0,037
0,087
0,046
0,101
0,054
4 Ap1 max 0,05 x D* 100 – 120 Ap1 max 0,2 x D 50 – 60
fz
0,052
0,064
0,074
H 1 Ap1 max 0,05 x D* 160 – 280 Ap1 max 0,2 x D 80 – 140
fz
0,062
0,077
0,088
*For cutting data above, use ae ) 0,8mm.
NOTE: Lower value of cutting speed is used for high stock removal applications or for higher hardness (machinability) within group.
Higher value of cutting speed is used for nishing applications or for lower hardness (machinability) within group.
Above parameters are based on ideal conditions. For smaller taper machining centres, please adjust parameters accordingly on >12mm diameters.
For nishing, increase feed per tooth by 20%.
