High-Performance Solid Carbide End Mills • VariMill™
Series 57NC • VariMill II™ • With Neck • With Centre Cut • Victory™ Grades
• Unequal flute spacing.
• Centre cutting.
• Single tool for both roughing and finishing
operations requiring fewer setups.
• Slotting up to 1 x D.
• Standard items listed. Additional styles
and coatings made-to-order.
D1
)3
> 3-6
> 6–10
> 10–18
> 18–30
End Mill Tolerances
tolerance e8
-0,014/-0,028
-0,020/-0,038
-0,025/-0,047
-0,032/-0,059
-0,040/-0,073
D
)3
> 3–6
> 6–10
> 10–18
> 18–30
Series 57NC • VariMill II • With Neck • With Centre Cut • Victory Grades
tolerance h6
+/-
0/-0,006
0/-0,008
0/-0,009
0/-0,011
0/-0,013
first choice
alternate choice
WS15PE
AlTiN
order # catalogue #
5598906 57NC06002T
5598907 57NC06022T
5598909 57NC06032T
—
5599072 57NC08003T
5599073 57NC08023T
5599075 57NC08033T
—
5599078 57NC10004T
5599079 57NC10024T
5599081 57NC10034T
5599083 57NC10054T
5599085 57NC12005T
5599086 57NC12025T
5599088 57NC12035T
5599090 57NC12055T
5599092 57NC16006T
5599093 57NC16026T
5599094 57NC16036T
5599096 57NC16056T
WS15PE
AlTiN
order #
5598908
5599070
5599071
5599074
5599076
5599077
5599080
5599082
5599084
5599087
5599089
5599091
5598905
5599095
5599097
catalogue #
—
57NC06022W
57NC06032W
57NC06042W
—
57NC08023W
57NC08033W
57NC08053W
—
57NC10024W
57NC10034W
57NC10054W
—
57NC12025W
57NC12035W
57NC12055W
—
57NC16026W
57NC16036W
57NC16056W
length of cut
D1 D D3
Ap1 max
6,0 6 5,64
13,00
6,0 6 5,64
13,00
6,0 6 5,64
13,00
6,0 6 5,64
13,00
8,0 8 7,52
19,00
8,0 8 7,52
19,00
8,0 8 7,52
19,00
8,0 8 7,52
19,00
10,0 10 9,40
22,00
10,0 10 9,40
22,00
10,0 10 9,40
22,00
10,0 10 9,40
22,00
12,0 12 11,28
26,00
12,0 12 11,28
26,00
12,0 12 11,28
26,00
12,0 12 11,28
26,00
16,0 16 15,04
32,00
16,0 16 15,04
32,00
16,0 16 15,04
32,00
16,0 16 15,04
32,00
L3
18,00
18,00
18,00
18,00
24,00
24,00
24,00
24,00
30,00
30,00
30,00
30,00
36,00
36,00
36,00
36,00
48,00
48,00
48,00
48,00
length
L
63
63
63
63
76
76
76
76
76
76
76
76
83
83
83
83
100
100
100
100
R
—
0,50
1,00
1,50
—
0,50
1,00
2,00
—
0,50
1,00
2,00
—
0,50
1,00
2,00
—
0,50
1,00
2,00
(continued)
