High-Performance Solid Carbide End Mills • Finishing
Series 4503 JJ • JIS • Victory™ Grades
• Centre cutting.
• Standard items listed. Additional
styles and coatings made-to-order.
Series 4503 JJ • Victory Grades
graWdePW15PP1E5PE
AlTiN
order #
5559170
5559171
5559172
5559173
5559174
5559175
5559176
5559177
5559178
5559179
5559180
5559181
5559182
5559183
5559184
5559185
catalogue #
450301001T
450301501T
450302001T
450302501T
450302511T
450303002T
450303502T
450304002T
450304502T
450305002T
450306002T
45030003T
450310004T
450312005T
450316006T
450320007T
D1
1,0
1,5
2,0
2,5
2,5
3,0
3,5
4,0
4,5
5,0
6,0
8,0
10,0
12,0
16,0
20,0
D1
)3
> 3–6
> 6–10
> 10–18
> 18–30
End Mill Tolerances
tolerance e8
-0,014/-0,028
-0,020/-0,038
-0,025/-0,047
-0,032/-0,059
-0,040/-0,073
D
)3
> 3–6
> 6–10
> 10–18
> 18–30
tolerance h6
+/-
0/-0,006
0/-0,008
0/-0,009
0/-0,011
0/-0,013
first choice
alternate choice
length of cut
length
D Ap1 max L
4 3,00 50
4 3,00 50
4 3,00 50
4 4,00 50
4 5,00 50
6 8,00 50
6
12,00
50
6
12,00
50
6
14,00
50
6
14,00
50
6
16,00
50
8
20,00
63
10 22,00 76
12 25,00 76
16 32,00 89
20
38,00
104
