Series 024111
для размещения заказа - zakaz@widiahanita.ru
High-Performance Solid Carbide End Mills • Finishing
Application Data • Series 024111
Side Milling (A)
and Slotting (B)
uncoated
Recommended feed per tooth (fz = mm/th) for side milling (A).
For slotting (B), reduce fz by 20%.
Material
Group
A
ap ae
B
Cutting Speed — vc
m/min
D1 — Diameter
ap min
max mm 2,0 3,0 4,0 5,0 6,0
N 6 0,7 x D 0,5 x D 0,5 x D 100 – 750 fz 0,020 0,030 0,040 0,050 0,060
NOTE: Lower value of cutting speed is used for high stock removal applications or for higher hardness (machinability) within group.
Higher value of cutting speed is used for nishing applications or for lower hardness (machinability) within group.
8,0
0,080
10,0
0,100
12,0
0,120
