High-Performance Solid Carbide End Mills • Hard Materials
Application Data • Series 70N7 • Vision Plus™ X-Feed™
Series 70N7 • Vision Plus X-Feed
Prole Milling
AlTiN
Recommended Feed Per Tooth (fz = mm/th) for 3D milling/proling (A)
Material
Group
A
ap ae
Cutting Speed — vc
m/min
min max
mm
6,0
D1 — Diameter
8,0 10,0 12,0 16,0 20,0
2 0,03 x D 0,55 x D 100 – 120
fz 0,200 0,300 0,300 0,400 0,500 0,600
H 3 0,03 x D 0,55 x D 80 – 100
fz 0,200 0,300 0,300 0,400 0,500 0,600
4 0,03 x D 0,55 x D
50
–
70
fz 0,150 0,200 0,250 0,300 0,400 0,500
NOTE: Above parameters are based on ideal conditions. For smaller taper machining centres, please adjust parameters accordingly on diameters >12mm.
