High-Performance Solid Carbide End Mills • Hard Materials
Series 7N02 • Vision Plus™ Micro
(Series 7N02 • Series 7N02 7N12 7N22 • Vision Plus Micro — continued)
L3
first choice
alternate choice
gradAelTAiNlT-MiNJ-M1 J1
gradTeiATlNiA-RlNJ-1RJ1
AlTiN
TiAlN
length of cut
length
order # catalogue #
order # catalogue #
D1 D
D3
Ap1 max
L3
L
3321565 7N2201601MJ 2256474 7N2201601RJ 1,6 4 1,57
2,40
6,00 50
3321524 7N0201602MJ 2256399 7N0201602RJ 1,6 6 1,54
3321528 7N1201602MJ 2256410 7N1201602RJ 1,6 6 1,54
2,40
2,40
4,00 50
8,00 60
3321570 7N2201701MJ 2256479 7N2201701RJ 1,7 4 1,64
2,60
6,00 50
3321571 7N2201711MJ 2256480 7N2201711RJ 1,7 4 1,64
2,60
10,00
50
3321572 7N2201721MJ 2256481 7N2201721RJ 1,7 4 1,64
2,60
12,00
50
3321573 7N2201731MJ 2256482 7N2201731RJ 1,7 4 1,64
2,60
16,00
50
3321574 7N2201741MJ 2256483 7N2201741RJ 1,7 4 1,64
2,60
20,00
63
3321575 7N2201801MJ 2256484 7N2201801RJ 1,8 4 1,74
2,70
6,00 50
3321576 7N2201811MJ 2256485 7N2201811RJ 1,8 4 1,74
2,70
10,00
50
3321577 7N2201821MJ 2256486 7N2201821RJ 1,8 4 1,74
2,70
12,00
50
3321578 7N2201831MJ 2256487 7N2201831RJ 1,8 4 1,74
2,70
16,00
50
3321579 7N2201841MJ 2256488 7N2201841RJ 1,8 4 1,74
2,70
20,00
63
3321525 7N0201802MJ 2256400 7N0201802RJ 1,8 6 1,74
2,70
4,50 50
3089254 7N1201802MJ 2256411 7N1201802RJ 1,8 6 1,74
3321580 7N2201901MJ 2256489 7N2201901RJ 1,9 4 1,84
2,70
2,80
9,00 60
6,00 50
3321581 7N2201911MJ 2256490 7N2201911RJ 1,9 4 1,84
2,80
10,00
50
3321582 7N2201921MJ 2256491 7N2201921RJ 1,9 4 1,84
2,80
12,00
50
3321583 7N2201931MJ 2256492 7N2201931RJ 1,9 4 1,84
2,80
16,00
50
3321584 7N2201941MJ 2256493 7N2201941RJ 1,9 4 1,84
2,80
20,00
63
3321585 7N2202001MJ 2256494 7N2202001RJ 2,0 4 1,96
3,00
6,00 50
3321586 7N2202011MJ 2256495 7N2202011RJ 2,0 4 1,96
3,00
10,00
50
3321587 7N2202021MJ 2256496 7N2202021RJ 2,0 4 1,96
3,00
16,00
50
3321588 7N2202031MJ 2256497 7N2202031RJ 2,0 4 1,96
3,00
20,00
63
3321589 7N2202041MJ 2256498 7N2202041RJ 2,0 4 1,96
3,00
20,00
75
3089247 7N0202002MJ 2256401 7N0202002RJ 2,0 6 1,96
3,00
5,00 50
3089255 7N1202002MJ 2256412 7N1202002RJ 2,0 6 1,96
3,00
10,00
60
—
3454429 7N2202051RJ 2,1 4 2,00
3,00
8,00 50
—
3454430 7N2202061RJ 2,1 4 2,00
3,00
12,00
50
—
3454431 7N2202071RJ 2,1 4 2,00
3,00
14,00
50
—
3454432 7N2202091RJ 2,1 4 2,00
3,00
25,00
63
3321590 7N2202501MJ 2256499 7N2202501RJ 2,5 4 2,40
3,70
8,00 50
(continued)
