High-Performance Solid Carbide End Mills • Hard Materials
Series 422875 • Vision Plus™
• Centre cutting.
• Standard items listed. Additional styles
and coatings made-to-order.
Larger than 4mm
Series 422875 • Vision Plus
D1
)3
> 3–6
> 6–10
> 10–18
> 18–30
End Mill Tolerances
tolerance h8
+/-
D
0/0,014
)3
0/0,018
> 3–6
0/0,022
> 6–10
0/0,027
> 10–18
0/0,033
> 18–30
tolerance h6
+/-
0/0,006
0/0,008
0/0,009
0/0,011
0/0,013
first choice
alternate choice
graKde10KU1F0-UDFC-HDPCHP
AlTiN
order # catalogue #
D1 D
length of cut
length
D3 Ap1 max L3
L R
2343319 422875-002003
2,0
6
1,90
2,00 17,50 70 0,30
2343303 422875-002005
2,0
6
1,90
2,00 17,50 70 0,50
2343305 422875-003005
3,0
6
2,90
3,00 18,50 70 0,50
2343321 422875-003010
3,0
6
2,90
3,00 18,50 70 1,00
2343307 422875-004005
4,0
6
3,80
4,00 19,50 80 0,50
2343323 422875-004010
4,0
6
3,80
4,00 19,50 80 1,00
2343309 422875-005005
5,0
6
4,80
5,00 42,00 80 0,50
2343325 422875-005010
5,0
6
4,80
5,00 42,00 80 1,00
2343327 422875-006005
6,0
6
5,80
6,00 42,00 80 0,50
2343311 422875-006010
6,0
6
5,80
6,00 42,00 80 1,00
2629541 422875-008005
8,0
8
7,80
8,00 51,00 90 0,50
2343329 422875-008010
8,0
8
7,80
8,00 51,00 90 1,00
2629555 422875-008015
8,0
8
7,80
8,00 51,00 90 1,50
2343313 422875-008020
8,0
8
7,80
8,00 51,00 90 2,00
2629559 422875-010005 10,0 10
9,70
10,00
57,00 100 0,50
2629560 422875-010010 10,0 10
9,70
10,00
57,00 100 1,00
3048961 422875-010015 10,0 10
9,70
10,00
57,00 100 1,50
2343331 422875-010020 10,0 10
9,70
10,00
57,00 100 2,00
2343315 422875-010030 10,0 10
9,70
10,00
57,00 100 3,00
2629561 422875-012005 12,0 12 11,70
12,00
62,00 110 0,50
2629573 422875-012010 12,0 12 11,70
12,00
62,00 110 1,00
2343333 422875-012030 12,0 12 11,70
12,00
62,00 110 3,00
2343317 422875-012040 12,0 12 11,70
12,00
62,00 110 4,00
