High-Performance Solid Carbide End Mills • Hard Materials
Series 7505 7515 7525 7545 • Vision Plus™
• Centre cutting.
• Standard items listed. Additional styles
and coatings made-to-order.
L
D1
Series 7505 7515 7525 7545 • Vision Plus
End Mill Tolerances
tolerance h6
D1 tolerance e8
D
+/-
) 3 -0,014/-0,028 ) 3
D
> 3–6
-0,020/-0,038
> 3–6
0/0,006
0/0,008
> 6–10
-0,025/-0,047
> 6–10
0/0,009
> 10–18
-0,032/-0,059
> 10–18
0/0,011
> 18–30
-0,040/-0,073
> 18–30
0/0,013
first choice
alternate choice
graTdiAe lTNiA-lLNT-L1T1
TiAlN
order #
2499570
2499567
2499571
2499568
2499572
2499569
1848805
1724468
1724487
1860603
1724463
1724469
1724489
1860604
1724464
1724481
1724490
1860605
1724465
1724482
catalogue #
754503002LT
750503002LT
754504002LT
750504002LT
754505002LT
750505002LT
754506002LT
751506002LT
752506002LT
754508003LT
750508003LT
751508003LT
752508003LT
754510004LT
750510004LT
751510004LT
752510004LT
754512005LT
750512005LT
751512005LT
D1 D
3,0 6
3,0 6
4,0 6
4,0 6
5,0 6
5,0 6
6,0 6
6,0 6
6,0 6
8,0 8
8,0 8
8,0 8
8,0 8
10,0 10
10,0 10
10,0 10
10,0 10
12,0 12
12,0 12
12,0 12
length of cut
Ap1 max
4,50
4,50
6,00
6,00
7,50
7,50
9,00
15,00
21,00
12,00
12,00
20,00
28,00
15,00
15,00
25,00
35,00
18,00
18,00
30,00
length
L
50
57
50
57
50
76
50
76
76
63
100
100
100
76
100
100
100
76
125
125
ZU
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
5
5
4
4
6
