High-Performance Solid Carbide End Mills • Hard Materials
Series 422871 • Vision Plus™
• Centre cutting.
• Standard items listed. Additional styles
and coatings made-to-order.
Series 422871 • Vision Plus
graKde10KU1F0-UDFC-DHCPHP
AlTiN
order # catalogue #
2343218 422871-030075
2343220 422871-030100
2343222 422871-040075
2343224 422871-040100
2343227 422871-050075
2343229 422871-050100
2343230 422871-060075
2343233 422871-060100
2343235 422871-080100
2343237 422871-080150
2343239 422871-100100
2343241 422871-100150
D1
3,0
3,0
4,0
4,0
5,0
5,0
6,0
6,0
8,0
8,0
10,0
10,0
D1
)3
> 3–6
> 6–10
> 10–18
> 18–30
End Mill Tolerances
tolerance h8
+/-
D
0/0,014
)3
0/0,018
> 3–6
0/0,022
> 6–10
0/0,027
> 10–18
0/0,033
> 18–30
tolerance h6
+/-
0/0,006
0/0,008
0/0,009
0/0,011
0/0,013
first choice
alternate choice
length of cut
length
D Ap1 max L
6 4,00 75
6 4,00 100
6 5,00 75
6 5,00 100
6 6,00 75
8 6,00 100
8 8,00 75
10 8,00 100
10
12,00
100
12
12,00
150
12
15,00
100
12
15,00
150
BETA
2.85
1.65
2.67
1.18
1.33
1.75
2.38
2.52
1.52
1.40
1.83
0.80
