General Purpose Solid Carbide End Mills • Roughing/Finishing
Series 4001 4011 4021 • VariMill™ GP
• Centre cutting.
• Standard items listed. Additional styles
and coatings made-to-order.
Series 4001 4011 4021 • VariMill GP
D1
)3
> 3–6
> 6–10
> 10–18
> 18–30
End Mill Tolerances
tolerance e8
-0,014/-0,028
-0,020/-0,038
-0,025/-0,047
-0,032/-0,059
-0,040/-0,073
D
)3
> 3–6
> 6–10
> 10–18
> 18–30
tolerance h6
+/-
0/0,006
0/0,008
0/0,009
0/0,011
0/0,013
first choice
alternate choice
grUaNdeCOUNATCEODAT- E..D
order # catalogue #
gradTeiATlNiAlN
TiAlN
order # catalogue #
length of cut
length
D1 D
Ap1 max
L
5880425 40010100T004
5880387 40010100T004
1,0
3
4,00
38
5880426 40010150T005
5880388 40010150T005
1,5
3
5,00
38
5880427 40010200T006
5880389 40010200T006
2,0
3
6,30
38
5880428 40010250T007
5880390 40010250T007
2,5
3
7,00
38
5880429 40010300T009
5880391 40010300T009
3,0
3
9,50
38
—
5880392 40010350T012
3,5
4
12,00
50
5880430 40010400T012
5880393 40010400T012
4,0
4
12,00
50
5880431 40110400T019
5880395 40110400T019
4,0
4
19,00
63
5880432 40210400T031
5880396 40210400T031
4,0
4
31,00
75
5880433 40010500T014
—
5,0 5
14,00
50
—
5880397 40210500T014
5,0
6
14,00
50
5880435 40010600T020
5880398 40010600T020
6,0
6
20,00
63
5880436 40110600T028
5880399 40110600T028
6,0
6
28,00
76
5880437 40210600T038
5880400 40210600T038
6,0
6
38,00
100
5880438 40010800T020
5880401 40010800T020
8,0
8
20,00
63
5880439 40110800T028
5880402 40110800T028
8,0
8
28,00
76
5880440 40210800T040
5880403 40210800T040
8,0
8
40,00
100
5880441 40011000T022 5880404 40011000T022 10,0 10
22,00
76
5880442 40111000T032 5880405 40111000T032 10,0 10
32,00
89
5880443 40211000T045 5880406 40211000T045 10,0 10
45,00
100
