General Purpose Solid Carbide End Mills • Roughing/Finishing
Series D010 • VariMill™ GP
• Centre cutting.
• Standard items listed. Additional styles
and coatings made-to-order.
Series D010 • VariMill GP
D1
)3
> 3–6
> 6–10
> 10–18
> 18–30
End Mill Tolerances
tolerance e8
-0,014/-0,028
-0,020/-0,038
-0,025/-0,047
-0,032/-0,059
-0,040/-0,073
D
)3
> 3–6
> 6–10
> 10–18
> 18–30
tolerance h6
+/-
0/0,006
0/0,008
0/0,009
0/0,011
0/0,013
first choice
alternate choice
grUaNdeCOUNATCEODAT- E..D
graTdieATlNiAlN
TiAlN
order # catalogue # order # catalogue #
5825604 D0100300T008 5825527 D0100300T008
grUaNdeCOUANTCEODA-TE..D
order # catalogue #
—
graTdieATlNiAlN
TiAlN
order # catalogue #
—
length of cut length
D1 D Ap1 max
L
3,0 6
8,00
57
5825605 D0100400T011 5825528 D0100400T011
—
—
4,0 6
11,00
57
5825606 D0100500T013 5825529 D0100500T013
—
—
5,0 6
13,00
57
5825607 D0100600T013 5825530 D0100600T013
—
—
6,0 6
13,00
57
5825608 D0100800T019 5825531 D0100800T019
—
—
8,0 8
19,00
63
5825609 D0101000T022 5825532 D0101000T022
—
—
10,0 10
22,00
72
5825610 D0101200T026 5825533 D0101200T026 5825589 D0101200W026 5825540 D0101200W026 12,0 12
26,00
83
5825611 D0101400T026 5825534 D0101400T026 5825590 D0101400W026 5825541 D0101400W026 14,0 14
26,00
83
5825612 D0101600T032 5825536 D0101600T032 5825591 D0101600W032 5825542 D0101600W032 16,0 16
32,00
92
5825613 D0101800T032 5825538 D0101800T032 5825592 D0101800W032 5825543 D0101800W032 18,0 18
32,00
92
5825614 D0102000T038 5825539 D0102000T038 5825593 D0102000W038 5825544 D0102000W038 20,0 20
38,00
104
NOTE: For application data, please see page P42.
