WIDIA™ VariTurn™
Stainless Steel • Austenitic Stainless Steels
Step 1 • Select the insert geometry
Negative Inserts
feed rate (mm/rev)
2P
Finishing
Positive Inserts
1P
Finishing
feed rate (mm/rev)
4P
Medium
feed rate (in/rev)
feed rate (in/rev)
6P
Roughing
Step 2 • Select the grade
cutting condition
heavily interrupted cut
lightly interrupted cut
varying depth of cut,
casting, or forging skin
smooth cut, pre-turned surface
2P
TN15M/TN10
TN15M/TN10
TN15M
TN15M
Negative Insert
Geometry
4P
TN30M
TN30M
TN15M/TN30M
TN15M
6P
TN30M
TN30M
TN15M/TN30M
TN15M
Positive Insert
Geometry
1P
TN30M/TN10
TN30M
TN15M/TN30M
TN15M
Step 3 • Selecting the cutting speed
Austenitic Stainless Steel
Material
Group
grade
TN15M
TN30M
M1
TN10U
TN15U
Austenitic Stainless Steel
Material
Group
grade
TN15M
TN30M
M2
TN10U
TN15U
speed — m/min
Starting Conditions
90 135 180 225 270 315 360 405 450
m/min
162
135
194
129
speed — m/min
Starting Conditions
90 135 180 225 270 315 360 405 450
m/min
149
135
180
120
Austenitic Stainless Steel: Duplex
(Ferritic and Austenitic Mixture)
Material
Group
grade
TN15M
TN30M
M3
TN10U
TN15U
90
speed — m/min
Starting Conditions
135 180 225 270 315 360 405 450
m/min
135
108
167
111
B114
