High-Performance High-Speed Steel (HSS-E/PM) • Roughing
Application Data • Series 664W 660W 661W • WavCut I™
Series 664W 660W 661W • WavCut I
Side Milling (A)
and Slotting (B)
uncoated
Recommended feed per tooth (fz = mm/th) for side milling (A).
For slotting (B), reduce fz by 20%.
Material
Group
A
B
Cutting Speed — vc
m/min
D1 — Diameter
ap ae ap min
max mm
25,0
32,0
40,0
50,0
P
5
1,5 x D 0,4 x D
1xD
10 –
14
fz
0,091
0,105
0,124
0,146
1
1,5 x D 0,4 x D
1xD
M
2
1,5 x D 0,4 x D
1xD
10 –
10 –
14
12
fz
0,114
0,131
0,155
fz
0,091
0,105
0,124
0,182
0,146
3 1,5 x D 0,4 x D 0,75 x D 6 – 11
S
4 1,5 x D 0,4 x D 0,75 x D 6 – 11
fz
0,091
0,105
0,124
fz
0,084
0,096
0,114
0,146
0,134
NOTE: Lower value of cutting speed is used for high stock removal applications or for higher hardness (machinability) within group.
Higher value of cutting speed is used for nishing applications or for lower hardness (machinability) within group.
Above parameters are based on ideal conditions. For smaller taper machining centres, please adjust parameters accordingly on diameters >12mm.
Application Data • Series 6N06
Series 6N06
Side Milling (A)
and Slotting (B)
Material
Group
A
ap ae
B
ap
TiCN
TiAlN
Cutting
Speed — vc
m/min
min max
Cutting
Speed — vc
m/min
min max
mm
Recommended feed per tooth (fz = mm/th) for side milling (A).
For slotting (B), reduce fz by 20%.
D1 — Diameter
6,0 8,0 10,0 12,0 16,0 18,0 20,0 25,0 30,0
1 1,5 x D 0,5 x D 1 x D 56 – 64 70 – 80 fz 0,046 0,062 0,072 0,079 0,097 0,104 0,109 0,119 0,143
2 1,5 x D 0,5 x D
P
3 1,5 x D 0,5 x D
1xD
1xD
48 – 64
40 – 56
60 – 80
50 – 70
fz 0,046 0,062 0,072 0,079 0,097 0,104 0,109 0,119 0,143
fz 0,038 0,052 0,061 0,067 0,084 0,091 0,097 0,109 0,131
5 1,5 x D 0,5 x D 1 x D 20 – 28 25 – 35 fz 0,031 0,042 0,048 0,054 0,067 0,073 0,078 0,087 0,105
1 1,5 x D 0,5 x D 1 x D 20 – 28 25 – 35 fz 0,038 0,052 0,061 0,067 0,084 0,091 0,097 0,109 0,131
M 2 1,5 x D 0,5 x D 1 x D 20 – 24 25 – 30 fz 0,031 0,042 0,048 0,054 0,067 0,073 0,078 0,087 0,105
3 1,5 x D 0,5 x D 1 x D 12 – 16 15 – 20 fz 0,026 0,035 0,040 0,045 0,055 0,059 0,062 0,068 0,082
1 1,5 x D 0,5 x D
K
2 1,5 x D 0,5 x D
1xD
1xD
56 – 64
40 – 56
70 – 80
50 – 70
fz 0,046 0,062 0,072 0,079 0,097 0,104 0,109 0,119 0,143
fz 0,038 0,052 0,061 0,067 0,084 0,091 0,097 0,109 0,131
1 1,5 x D 0,5 x D 1 x D 12 – 24 15 – 30 fz 0,038 0,052 0,061 0,067 0,084 0,091 0,097 0,109 0,131
2 1,5 x D 0,5 x D
S
3 1,5 x D 0,5 x D
1xD
1xD
4 – 12
12 – 22
5 – 15
15 – 28
fz 0,021 0,027 0,032 0,036 0,045 0,048 0,052 0,059 0,071
fz 0,031 0,042 0,048 0,054 0,067 0,073 0,078 0,087 0,105
4 1,5 x D 0,5 x D 1 x D 12 – 22 15 – 28 fz 0,027 0,038 0,045 0,050 0,062 0,067 0,071 0,080 0,096
NOTE: Lower value of cutting speed is used for high stock removal applications or for higher hardness (machinability) within group.
Higher value of cutting speed is used for nishing applications or for lower hardness (machinability) within group.
Above parameters are based on ideal conditions. For smaller taper machining centres, please adjust parameters accordingly on diameters >12mm.
