Solid Carbide Drills
TOP DRILL S™ with Through Coolant • Steel and Cast Iron
(TDS402A • TDS412A • 5 x D — continued)
graWdePW20PP2D0PD
TiAlN
graWdeKW15KP1D5PD
AlCrN
D1 diameter
first choice
alternate choice
order # catalogue # order # catalogue # mm in L L3 L4 max L5 LS D
4163094 TDS402A09921
4158891 TDS412A09921
9,921
.3906
103
61
49 1,7 40 10
4162803 TDS402A10000
4162804 TDS402A10100
4156602 TDS412A10000
4156733 TDS412A10100
10,000
10,100
.3937
.3976
103
118
61
71
49 1,7 40 10
56 1,7 45 12
4162805 TDS402A10200
4156734 TDS412A10200
10,200
.4016
118
71
56 1,7 45 12
4162806 TDS402A10300
4162807 TDS402A10320
4156735 TDS412A10300
4156736 TDS412A10320
10,300
10,320
.4055
.4063
118
118
71
71
56 1,8 45 12
56 1,8 45 12
4162808 TDS402A10400
4156737 TDS412A10400
10,400
.4094
118
71
56 1,8 45 12
4162809 TDS402A10500
4162810 TDS402A10600
4156738 TDS412A10500
4156739 TDS412A10600
10,500
10,600
.4134
.4173
118
118
71
71
56 1,8 45 12
56 1,8 45 12
4162811 TDS402A10700
4162812 TDS402A10716
4156740 TDS412A10700
4156741 TDS412A10716
10,700
10,716
.4213
.4219
118
118
71
71
56 1,8 45 12
56 1,8 45 12
4162813 TDS402A10800
4156742 TDS412A10800
10,800
.4252
118
71
56 1,8 45 12
4162814 TDS402A10900
4162815 TDS402A11000
4156743 TDS412A10900
4156744 TDS412A11000
10,900
11,000
.4291
.4331
118
118
71
71
56 1,9 45 12
56 1,9 45 12
4162816
4162817
4162818
TDS402A11100
TDS402A11113
TDS402A11200
4156745
4156746
4156747
TDS412A11100
TDS412A11113
TDS412A11200
11,100
11,113
11,200
.4370
.4375
.4409
118
118
118
71
71
71
56 1,9 45 12
56 1,9 45 12
56 1,9 45 12
4162819 TDS402A11300
4162820 TDS402A11400
4156748 TDS412A11300
4156749 TDS412A11400
11,300
11,400
.4449
.4488
118
118
71
71
56 1,9 45 12
56 2,0 45 12
4162821 TDS402A11500
4156750 TDS412A11500
11,500
.4528
118
71
56 2,0 45 12
4162822 TDS402A11509
4162823 TDS402A11600
4156751 TDS412A11509
4156752 TDS412A11600
11,509
11,600
.4531
.4567
118
118
71
71
56 2,0 45 12
56 2,0 45 12
4162824 TDS402A11700
4162825 TDS402A11800
4156753 TDS412A11700
4156754 TDS412A11800
11,700
11,800
.4606
.4646
118
118
71
71
56 2,0 45 12
56 2,0 45 12
4162826 TDS402A11900
4156755 TDS412A11900
11,900
.4685
118
71
56 2,0 45 12
4162827 TDS402A11908
4162828 TDS402A12000
4156756 TDS412A11908
4156757 TDS412A12000
11,908
12,000
.4688
.4724
118
118
71
71
56 2,0 45 12
56 2,1 45 12
4162829 TDS402A12100
4156758 TDS412A12100
12,100
.4764
124
77
60 2,1 45 14
4162830 TDS402A12200
4162831 TDS402A12300
4156759 TDS412A12200
4156760 TDS412A12300
12,200
12,300
.4803
.4843
124
124
77
77
60 2,1 45 14
60 2,1 45 14
4162832 TDS402A12304
4162833 TDS402A12400
4156761 TDS412A12304
4156762 TDS412A12400
12,304
12,400
.4844
.4882
124
124
77
77
60 2,1 45 14
60 2,1 45 14
4162834 TDS402A12500
4156763 TDS412A12500
12,500
.4921
124
77
60 2,1 45 14
4162835 TDS402A12600
4156764 TDS412A12600
12,600
.4961
124
77
4162836 TDS402A12700
4156765 TDS412A12700
12,700
.5000
124
77
60 2,2 45 14
60 2,2 45 14
4162837
4162838
4162839
4162840
4162841
TDS402A12800
TDS402A12900
TDS402A13000
TDS402A13096
TDS402A13100
4156766 TDS412A12800
4156767 TDS412A12900
4156768 TDS412A13000
4156769 TDS412A13096
4156770 TDS412A13100
12,800
12,900
13,000
13,096
13,100
.5039
.5079
.5118
.5156
.5157
124
124
124
124
124
77
77
77
77
77
60 2,2 45 14
60 2,2 45 14
60 2,2 45 14
60 2,3 45 14
60 2,3 45 14
(continued)
