Solid Carbide Drills
General Application Instructions
Shank Designs to DIN 6535
Form HE,
2° angle
Design F
Form HA,
straight
design A
Dimensions for WIDIA™ High-Performance Solid Carbide Drills
mm
DIN 6535
D1 min
D1 max
D
LS
1,000
1,400
4 28
1,401
1,900
4 28
1,901
2,300
4 28
2,301
2,999
4 28
3,000
3,750
6 36
3,751
4,750
6 36
4,751
6,000
6 36
6,001
7,000
8 36
7,001
8,000
8 36
8,001
10,000
10 40
10,001
12,000
12 45
12,001
14,000
14 45
14,001
16,000
16 48
16,001
18,000
18 48
18,001
20,000
20 50
20,001
22,000
20 50
22,001
25,000
25 56
* D1<20mm to DIN 6537K
D1>20mm to factory standard
** To factory standard
SHORT*
~3 x D
LONG*
~5 x D
EXTRA LONG**
~8 x D
L L3 L4 max L L3 L4 max L L3 L4 max
58 7
5
58 9
6
58 12
10
58 9
6
58 12
9
58 18
15
58 13
9
58 18 14 66 26 22
58 17
12
58 22
17
66 30
25
62 20
14
66 28
23
78 40
33
66 24
17
74 36
29
87 49
41
66 28
20
82 44
35
94 56
48
79 34
24
91 53
43 105 67
57
79 41
29
91 53
43 110 72
61
89 47 35 103 61
49 122 80
68
102 55 40 118 71
56 141 94
79
107 60 43 124 77
60 155 108 91
115 65 45 133 83
63
171 121
101
123 73 51 143 93
71
185 135
113
131 79
55
153 101
77
200 148
124
141 86
60
167 112
85
217 162
136
153 95
65
184 126
98
238 180
150
NOTE: Solid Carbide Drills from WIDIA in short and regular lengths conform to DIN 6537.
Drills with long lengths conform to WIDIA factory standard.
Solid Carbide Drills with diameter D1>20mm (not DIN 6537) are also standardised to factory standard.
Tolerances of Drills and Holes
High-performance solid carbide drills with tolerances of m7 create holes with
tolerances of H9. H8 can be achieved in very good conditions. The drill should
be used for holes in H8, and in favourable conditions, H7 can be achieved.
Solid carbide drills with H7 create holes in K9–K11. Other drilling tolerances
require special solid carbide drill versions.
Tolerances of diameter D1 on:
Spiral Flute
TDG Drill
m
+55
+50
+45
+40
+35
+30
+25
+20
+15
+10
+5
0
3<D 6
6<D10
10<D 18
18<D 30
