Spade Blade Holders
Straight Shank
Straight Flute Holders • Inch • Long
D1 D1 max
long mm in mm in
seat
L L1 L4 max LS D size
CS
insert
screw
Torx
wrench
7SZSL 11,10 .437 12,90 .508 7.76 5.38 3.10 2.38 .750
Z 1/8 - 27 NPT 56-1015 56-2026
7S0SL 12,93 .509 17,65 .695 9.13 6.75 4.60 2.38 .750
0 1/8 - 27 NPT 56-1014 56-2017
7S0.5SL 15,47 .609 17,65 .695 9.13 6.75 7.36 2.38 .750
— 1/8 - 27 NPT 56-1014 56-2017
7S1SL 17,53 .690 24,38 .960 11.10 8.72 6.34 2.38 1.000 1 1/4 - 18 NPT 56-1020 56-2028
7S2SL 24,41 .961 35,05 1.380 12.75 10.31 7.86 2.44 1.250 2 1/4 - 18 NPT 56-1018 56-2015
7S3SL 35,08 1.381 47,73 1.879 18.63 16.00 13.28 2.63 1.500 3 1/4 - 18 NPT 56-1585 56-2020
7S4SL 47,75 1.880 65,28 2.570 21.50 18.87 15.89 2.63 1.500 4 1/4 - 18 NPT 56-1585 56-2020
7S7SL 88,93 3.501 114,30 4.500 29.50 22.88 19.25 6.63 3.000 7 1/4 - 18 NPT 56-1025 56-2125
Straight Flute Holders • Inch • Extra Long
D1 D1 max
extra long
7S0SE
7S0.5SE
7S1SE
7S1.5SE
7S2SE
7S3SE
7S4SE
mm
12,93
15,47
17,53
21,82
24,41
35,08
47,75
in
.509
.609
.690
.859
.961
1.381
1.880
mm
17,65
17,65
24,38
24,38
35,05
47,73
65,28
in
.695
.695
.960
.960
1.380
1.879
2.570
L
12.17
12.17
15.12
15.13
15.82
25.51
—
L1
9.80
9.80
12.75
12.75
13.38
22.88
—
L4 max
7.44
7.60
5.67
10.29
11.07
20.16
15.89
LS
2.38
2.38
2.38
2.38
2.44
2.63
2.63
D
.750
.750
1.000
1.000
1.250
1.500
1.500
seat
size CS
insert
screw
0 1/8 - 27 NPT 56-1014
— 1/8 - 27 NPT 56-1014
1 1/4 - 18 NPT 56-1020
1.5 1/4 - 18 NPT 56-1020
2 1/4 - 18 NPT 56-1018
3 1/4 - 18 NPT 56-1585
4 1/4 - 18 NPT 56-1585
Torx
wrench
56-2017
56-2017
56-2028
56-2028
56-2015
56-2020
56-2020
