Spade Blade Holders
Taper Shank
Straight Flute Holders • Long
D1 D1 max
long
7SZTL
mm
11,10
in
.437
7S0TL
12,93 .509
7S1TL
17,53 .690
7S2TL
24,41 .961
7S3TL
35,08 1.381
7S4TL
47,75 1.880
7S5TL
63,50 2.500
7S7TL
88,93 3.501
NOTE: CSMS = Morse taper size.
mm
12,90
17,65
24,38
35,05
47,73
65,28
88,90
114,30
in
.508
.695
.960
1.380
1.879
2.570
3.500
4.500
L
8.51
9.88
12.60
14.19
20.88
23.75
26.88
30.53
L1
5.57
6.94
8.91
10.50
16.25
19.12
21.00
24.65
L4 max
3.30
4.60
6.36
7.86
13.28
15.90
17.13
19.75
CSMS
LS system size
3.13 2
3.13 2
3.88 3
3.88 3
4.88 4
4.88 4
6.13 5
6.13 5
seat
size
Z
0
1
2
3
4
5
7
CS
8 - 32
8 - 32
1/4 - 20
1/4 - 20
5/16-18
5/16-18
1/2 - 13
1/2 - 13
insert
screw
56-1015
56-1014
56-1020
56-1018
56-1585
56-1585
56-1025
56-1025
Torx
wrench
56-2026
56-2017
56-2028
56-2015
56-2020
56-2020
56-2125
56-2125
Straight Flute Holders • Extra Long
D1 D1 max
extra long mm
in
7S0TE
12,93 .509
7S0.5TE 15,47 .609
7S2TE
24,41 .961
NOTE: CSMS = Morse taper size.
mm
17,65
17,65
35,05
in
.695
.695
1.380
CSMS
L L1 L4 max LS system size
12.93 10.00 7.65 3.13
2
12.93 9.80
7.60 3.13
2
17.26 13.57 11.07 3.88
3
seat
size
0
—
2
CS
8 - 32
8 - 32
1/4 - 20
insert
screw
56-1014
56-1014
56-1018
Torx
wrench
56-2017
56-2017
56-2015
