Hole Finishing
ROTAFLEX™ High-Performance Boring Systems
• Basic body shipped without insert holders.
• Order insert holder, slides, or micro-adjustable
cartridges separately.
TCHS • KM™ Shank Series
order number
3861149
3861150
3861152
3861151
3861173
3861174
3861175
3861176
3861177
3861178
Spare Parts
catalogue number
KM32TSTCHS022030
KM32TSTCHS030039
KM40TSTCHS030039
KM32TSTCHS039050
KM40TSTCHS039050
KM40TSTCHS050067
KM50TSTCHS050067
KM50TSTCHS067088
KM63TSTCHS067088
KM63TSTCHS088115
L1 Assy
L1 Assy = L1 body + L1 insert holder
BR1 bore range
22,000-30,000
30,000-39,000
30,000-39,000
39,000-50,000
39,000-50,000
50,000-67,000
50,000-67,000
67,000-88,000
67,000-88,000
88,000-115,000
L1
52,7
67,7
87,7
63,7
83,7
78,2
88,2
95,7
95,7
93,7
CSMS
system size
KM32TS
KM32TS
KM40TS
KM32TS
KM40TS
KM40TS
KM50TS
KM50TS
KM63TS
KM63TS
kg
0,30
0,50
0,60
0,70
1,00
1,10
1,20
1,40
1,80
2,40
catalogue number
KM32TSTCHS022030
KM32TSTCHS030039
KM32TSTCHS039050
KM40TSTCHS030039
KM40TSTCHS039050
KM40TSTCHS050067
KM50TSTCHS050067
KM50TSTCHS067088
KM63TSTCHS067088
KM63TSTCHS088115
xing
screw
12147602700
12147602300
12147602400
12147602300
12147602400
12147602500
12147602500
12147602600
12147602600
12147602800
disc
washer
12147600100
12147603900
12147600200
12147603900
12147600200
12147604000
12147604000
12147600300
12147600300
12147600400
