High-Performance Taps
Grades and Grade Descriptions
для размещения заказа - zakaz@widiahanita.ru
Coatings are designed for
optimised tapping performance
in specic materials.
P Steel
M Stainless Steel
K Cast Iron
N Non-Ferrous
S High-Temp Alloys
H Hardened Materials
Coating
Grade Description
wear
resistance
toughness
05 10 15 20 25 30 35 40 45
Coated HSS-E-PM, PVD heat- and wear-resistant high-vanadium cobalt powder metal
HSS substrate with high-hardness TiCN coating. Use when tapping heat-treated steel
44–55 HRC and cobalt- or nickel-based heat-resistant alloys.
S
H
Coated HSS-E-PM, PVD powder metal HSS-E substrate with two-layer coating.
TiN base layer and DLC top layer that resists galling of non-ferrous materials
to the tap. Use for tapping titanium. Not recommended for steel.
S
Coated HSS-E-PM, PVD powder metal HSS-E substrate with DLC coating.
Use for form tapping aluminium. Not recommended for steel.
N
High-vanadium HSS-E substrate with a coating consists of low friction
CrC/C over wear-resistant TiN base layer. Use for tapping stainless steel
and non-ferrous materials.
N
P
Coated HSS-E substrate with TiCN PVD layer. Use in multiple applications, including
steel, stainless steel, ductile cast iron, and cast aluminium. WP42EG is more abrasion-
resistant than WU41EG.
M
K
N
X8
