WIDIA™ • Inserts for Machining Aluminium
Non-Ferrous Materials • Aluminium Alloys
Step 1 • Select the insert geometry
Positive Inserts
feed rate (mm/rev)
AL1
AL3
feed rate (in/rev)
Step 2 • Select the grade
cutting condition
heavily interrupted cut
lightly interrupted cut
varying depth of cut,
casting, or forging skin
smooth cut, pre-turned surface
Positive Insert Geometry
-AL1
HCK10/HWK10
-AL3
HCK10/HWK15
HCK10/HWK10
HCK10/HWK15
HCK10/HWK10
HCK10/HWK15
HCK10/HWK10
HCK10/HWK15
Step 3 • Selecting the cutting speed
Low-Silicon Aluminium Alloys
(hypoeutectic <12,2% Si) and Magnesium Alloys
speed — m/min
Starting Conditions
Material
Group
grade
250 500 750 1000 1250 1500 1750 2000 2250 2500
m/min
N2 HCK10
550
High-Silicon Aluminium Alloys
(hypereutectic >12,2% Si) and Magnesium Alloys
speed — m/min
Starting Conditions
Material
Group
grade
250 500 750 1000 1250 1500 1750 2000 2250 2500
m/min
N3 HCK10
550
B152
