• GP6520 TiCN for tapping steel
and cast iron.
для размещения заказа - zakaz@widiahanita.ru
High-Performance Taps
Victory™ Spiral-Flute HSS-E-PM Taps • Blind Holes
Shank Tolerance
D mm
tolerance h6
12–18
+0, -0,011
20–30
+0, -0,013
32–36
+0, -0,016
GT51 • Form C Semi-Bottoming Chamfer • Through Coolant • Larger Sizes • Metric Extra Long • For Steel
and Cast Iron
first choice
alternate choice
graGdeP6G5P260520
TiCN
order # catalogue #
4154269 GT515006
4154270 GT515007
4154271 GT515008
4154272 GT515009
4154273 GT515010
D1 size
metric dimensions
L L3 L2
D
number
of utes
class
of t
M24 X 3
200 30 120 18,0
4
6HX
M30 X 3,5 250 35 150 22,0
5
6HX
M33 X 3,5 250 35 150 25,0
5
6HX
M36 X 4
250 40 150 28,0
5
6HX
M42 X 4,5 300 45 180 32,0
6
6HX
