Multipurpose Taps
VariTap™ Spiral-Flute HSS-E Taps • Blind Holes
(VT-SFT • Form C Semi-Bottoming Chamfer • Metric DIN 371, 374, and 376 — continued)
first choice
alternate choice
graWdePW42PE4G2EG
TiCN
graWdeUW41UE4G1EG
TiN
graWdePW49PE4G9EG
Oxide
graWdeUW40UE4G0EG
Bright
order # catalogue # order # catalogue # order # catalogue # order # catalogue # D1 size
metric
dimensions
L L3 L2 D
number dimension class
of utes standard of t
5368741 VTSFT6518 5368740 VTSFT6518 5368742 VTSFT6518 5368743 VTSFT6518 M6 X 1 80 12 30 6,0 3 DIN 371 6H
– – 5402253 VTSFT6528 5402254 VTSFT6528 M6 X 1 80 12 30 4,5 3 DIN 376 6H
–
– 5368744 VTSFT6519 –
M6 X 1 80 12 30 6,0 3 DIN 371 6G
– – 5368745 VTSFT6520 5368746 VTSFT6520 M7 X 1 80 12 30 7,0 3 DIN 371 6H
– – 5402186 VTSFT6550 5402187 VTSFT6550 M8 X 0,75 80 12 30 6,0 3 DIN 374 6H
5402188 VTSFT6551
– 5402189 VTSFT6551 5402190 VTSFT6551 M8 X 1 90 15 35 6,0 3 DIN 374 6H
–
– 5368752 VTSFT6522 –
M8 X 1,25 90 15 35 8,0 3 DIN 371 6G
– – 5402255 VTSFT6529 5402256 VTSFT6529 M8 X 1,25 90 15 35 6,0 3 DIN 376 6H
5368749 VTSFT6521 5368748 VTSFT6521 5368750 VTSFT6521 5368751 VTSFT6521 M8 X 1,25 90 15 35 8,0 3 DIN 371 6H
– – – 5402191 VTSFT6552 M10 X 0,75 90 15 35 7,0 3 DIN 374 6H
– – 5402192 VTSFT6553 5402193 VTSFT6553 M10 X 1 90 15 35 7,0 3 DIN 374 6H
5402194 VTSFT6554
– 5402195 VTSFT6554 5402196 VTSFT6554 M10 X 1,25 100 18 39 7,0 3 DIN 374 6H
5368754 VTSFT6523 5368753 VTSFT6523 5368755 VTSFT6523 5368756 VTSFT6523 M10 X 1,5 100 18 39 10,0 3 DIN 371 6H
–
– 5368757 VTSFT6524 –
M10 X 1,5 100 18 39 10,0 3 DIN 371 6G
– – 5402257 VTSFT6530 5402258 VTSFT6530 M10 X 1,5 100 18 39 7,0 3 DIN 376 6H
– – 5402197 VTSFT6555 5402198 VTSFT6555 M12 X 1 100 21 39 9,0 3 DIN 374 6H
– – 5402199 VTSFT6556 5402200 VTSFT6556 M12 X 1,25 100 21 39 9,0 3 DIN 374 6H
5402201 VTSFT6557
– 5402202 VTSFT6557 5402203 VTSFT6557 M12 X 1,5 100 21 39 9,0 3 DIN 374 6H
– – 5402263 VTSFT6532 – M12 X 1,75 110 21 44 9,0 3 DIN 376 6G
5402260 VTSFT6531 5402259 VTSFT6531 5402261 VTSFT6531 5402262 VTSFT6531 M12 X 1,75 110 21 44 9,0 3 DIN 376 6H
– – – 5402204 VTSFT6558 M14 X 1 100 21 47 11,0 3 DIN 374 6H
– – – 5402205 VTSFT6559 M14 X 1,25 100 21 47 11,0 3 DIN 374 6H
5402206 VTSFT6560
– 5402207 VTSFT6560 5402208 VTSFT6560 M14 X 1,5 100 21 47 11,0 3 DIN 374 6H
–
– 5402268 VTSFT6534 –
M14 X 2 110 24 52 11,0 3 DIN 376 6G
5402265 VTSFT6533 5402264 VTSFT6533 5402266 VTSFT6533 5402267 VTSFT6533 M14 X 2 110 24 52 11,0 3 DIN 376 6H
– – – 5402209 VTSFT6561 M16 X 1 100 21 46 12,0 3 DIN 374 6H
– – 5402210 VTSFT6562 5402211 VTSFT6562 M16 X 1,5 100 21 46 12,0 3 DIN 374 6H
–
– 5402272 VTSFT6536 –
M16 X 2 110 24 51 12,0 3 DIN 376 6G
– 5402269 VTSFT6535 5402270 VTSFT6535 5402271 VTSFT6535 M16 X 2 110 24 51 12,0 3 DIN 376 6H
– – – 5402212 VTSFT6563 M18 X 1 110 21 50 14,0 4 DIN 374 6H
– – 5402214 VTSFT6564 5402213 VTSFT6564 M18 X 1,5 110 21 50 14,0 4 DIN 374 6H
– – – 5402215 VTSFT6565 M18 X 2 125 30 58 14,0 4 DIN 374 6H
– 5402273 VTSFT6537 5402274 VTSFT6537 5402275 VTSFT6537 M18 X 2,5 125 30 58 14,0 4 DIN 376 6H
– – – 5402216 VTSFT6566 M20 X 1 125 24 56 16,0 4 DIN 374 6H
– – 5402217 VTSFT6567 5402218 VTSFT6567 M20 X 1,5 125 24 56 16,0 4 DIN 374 6H
– – – 5402219 VTSFT6568 M20 X 2 140 30 64 16,0 4 DIN 374 6H
– 5402276 VTSFT6538 5402277 VTSFT6538 5402278 VTSFT6538 M20 X 2,5 140 30 64 16,0 4 DIN 376 6H
– – 5402220 VTSFT6569 5402221 VTSFT6569 M22 X 1,5 125 24 62 18,0 4 DIN 374 6H
– – – 5402222 VTSFT6570 M22 X 2 140 30 70 18,0 4 DIN 374 6H
– 5402279 VTSFT6539 5402280 VTSFT6539 5402281 VTSFT6539 M22 X 2,5 140 30 70 18,0 4 DIN 376 6H
(continued)
