High-Performance Taps
Victory™ Straight-Flute Carbide Taps • Blind and Through Holes
• WH16PG TiAlN/MoS2
for steel 55–63 HRC.
Shank Tolerance
D mm
tolerance h6
1–3 +0, -0,025
3,5–6
+0, -0,030
7–10 +0, -0,036
11–18
+0, -0,043
GX10 • Form C Semi-Bottoming Chamfer • Metric DIN 371, 374, and 376 • For Hard Steel
first choice
alternate choice
gradWeHW16HP1G6PG
TiAlN+MoS2
order # catalogue #
4158323 GX105001
4158324 GX105002
4158325 GX105003
4158326 GX105004
4158331 GX105009
4158327 GX105005
4158332 GX105010
4158328 GX105006
4158333 GX105011
4158329 GX105007
4158334 GX105012
4158330 GX105008
4158335 GX105013
D1 size
M3 X 0,5
M4 X 0,7
M5 X 0,8
M6 X 1
M8 X 1
M8 X 1,25
M10 X 1
M10 X 1,5
M12 X 1,5
M12 X 1,75
M14 X 1,5
M14 X 2
M16 X 1,5
metric dimensions
L L3 L2 D
63 6 18 4,5
63 8 20 4,5
70 10 26 6,0
80 12 28 6,0
90 15 35 8,0
90 15 35 8,0
100 18 38 10,0
100 18 38 10,0
110 21 41 12,0
110 21 41 12,0
110 24 44 14,0
110 24 44 14,0
110 24 44 16,0
number
of utes
4
4
4
4
5
5
5
5
5
5
5
6
5
dimension
standard
DIN 371
DIN 371
DIN 371
DIN 371
DIN 374
DIN 371
DIN 374
DIN 371
DIN 374
DIN 376
DIN 374
DIN 376
DIN 374
class
of t
6HX
6HX
6HX
6HX
6HX
6HX
6HX
6HX
6HX
6HX
6HX
6HX
6HX
Y46
