Technical Information
DIN 371 • DIN 376 • Nominal Dimensions
DIN 371
machine screw
size number
4
5
6
8
10
–
–
–
nominal fraction
diameter (in)
–
–
–
–
–
1/4
5/16
3/8
DL
3,5 56
4,0 56
4,0 56
4,5 63
6,0 70
7,0 80
8,0 90
10,0 100
metric dimensions
L3 L2
8 18
9 20
9 20
11 21
12 25
15 30
15 35
19 39
L5 S10
6 2,7
6 3,0
6 3,0
6 3,4
8 4,9
8 5,5
9 6,2
11 8,0
DIN 376
nominal fraction
diameter (in)
7/16
1/2
9/16
5/8
3/4
7/8
1
D
8
9
11
12
16
18
18
metric dimensions
L L3
100 18
110 23
110 25
110 24
140 30
140 34
160 38
L5
9
10
12
12
15
17
17
S10
6,2
7,0
9,0
9,0
12,0
14,5
14,5
Y94
