Technical Information
JIS • Nominal Dimensions
для размещения заказа - zakaz@widiahanita.ru
JIS Type 2 Metric Coarse
metric dimensions
D1
pitch
D
L L3 L2 L5 S10
M3 0.5 4 46 11 19 6 3.2
M3.5
0.6
4 48 13 20 6 3.2
M4 0.7 5 52 13 21 7 4
M4.5
0.75
5 55 13 21 7
4
M5 0.8 5.5 60 16 24 7 4.5
M6 1 6 62 19 29 7 4.5
JIS Type 3 Metric Coarse
D1 pitch
M8 1.25
M9 1.25
M10 1.5
M11 1.5
M12 1.75
M14 2
M16 2
M18 2.5
M20 2.5
M22 2.5
M24 3
D
6.2
7
7
8
8.5
10.5
12.5
14
15
17
19
metric dimensions
L L3
70 22
72 22
75 24
80 25
82 29
88 30
95 32
100 37
105 37
115 38
120 45
L5
8
8
8
9
9
11
13
14
15
16
18
S10
5
5.5
5.5
6
6.5
8
10
11
12
13
15
Y96
