Advanced Material Inserts
WBH25P™ Features and Benets
4 Large standard portfolio.
Standard edge preparation — the optimum combination of T-land
angle, T-land width, and hone size — is paramount in achieving
maximum performance. WIDIA™ has developed three standard
edge configurations, including wiper inserts.
• Light machining edge prep E.
• Medium machining edge prep S01015.
• Heavy machining edge prep S01025.
E: Honed cutting edge
S01015: W x = 0,10mm x 15°
S01025: W x = 0,10mm x 25°
These edge preps are available in common styles, sizes,
and nose radii in both positive and negative geometries.
W
` —T-Land Angle
5 CB1 chipbreaker in positive and negative geometries,
solving chipbreaking and chip control issues.
Chipbreaker — when machining case-hardened steel with a
hard outer skin and a tough and softer core, a chipbreaker
provides a great advantage. The CB1 chipbreaker is a proven
solution to effectively breaking chips. Long chips can form
bird nests, causing machine malfunctions, increasing scrap-
rates, and reducing the overall equipment effectiveness.
Available as a custom solution product.
Insert without Chipbreaker
Insert with Chipbreaker
• Log chips.
• Bird-nest formation.
• Chips are broken.
