WIDIA - Полный каталог инструмента - 2017
Advanced Material Inserts
Grades and Grade Descriptions
для размещения заказа - zakaz@widiahanita.ru
Reduce cycle times. High speed
and feed capability. Long tool life.
New multi-layer coating provides
better wear resistance.
Coating
Grade Description
P Steel
M Stainless Steel
K Cast Iron
N Non-Ferrous
S High-Temp Alloys
H Hardened Materials
wear
resistance
toughness
05 10 15 20 25 30 35 40 45
BN-H25
A PVD-TiAlN coating over a low content, CBN tip brazed onto a carbide insert.
Designed for roughing to finishing of hardened steels (>45 HRC). Use on bearing steel,
hot and cold work tool steels, high-speed steels, die steels, case-hardened steels,
carburised and nitrided irons, and some hard coatings.
H
BN-H30
DP-N10
A PVD-TiAlN coating over a low content, CBN tip brazed onto a carbide insert.
Designed for roughing to finishing in interrupted cuts on hardened steels (>45 HRC).
Applied on grey cast iron, chilled irons, high-chrome alloyed steels, high-temp alloys,
and sintered powdered metals.
K
S
H
An ultra-fine grained polycrystalline diamond (PCD) tip brazed onto a carbide
substrate. Designed for general purpose turning of primarily non-ferrous materials.
Applied over a wide range of continuous to interrupted cuts where superior surface
finish is needed. Use on low- to medium-silicon content aluminium alloys,
non-metallics, copper, brass, and zinc-based alloys. The ultra-fine grained diamond
particle size enables superior surface finishes while ensuring the best mechanical
shock resistance of any PCD cutting tool.
N
S
A multi-modal PCD grade with a range of grain sizes brazed onto a carbide substrate.
Engineered for extreme abrasion resistance and good edge strength for demanding
applications. An ideal choice for high-silicon aluminium alloys, bi-metallic (AL/GCI)
materials, MMC, carbon-fibre reinforced plastics, and other abrasive
non-metallic materials.
DP-N25
*Grade available as Custom Solution only.
N
B174
