P-Style Clamping Toolholders for Negative Inserts
See pages B47–B64
for inserts.
PDJN 93°
order number
right hand
3878424
3878429
3879318
3879151
3878425
3879152
3878426
left hand
3879313
3878427
3879317
3878428
3879314
3878423
3879315
3879316
catalogue number
PDJNR1616H11
PDJNR2020K11
PDJNR2020K15
PDJNR2525M11
PDJNR3225P15
PDJNR3232P15
PDJNR4025R15
PDJNL1616H11
PDJNL2020K11
PDJNL2020K15
PDJNL2525M11
PDJNL2525M15
PDJNL3225P15
PDJNL3232P15
PDJNL4025R15
H B F L1 L2 hS°
gage
insert
shim
shim
pin
16 16 20,0 100 22,0 -6.0 DN..110408 512.060 513.060
20 20 25,0 125 30,0 -7.0 DN..110408 512.060 513.060
20 20 25,0 125 36,0 -7.0 DN..150608 512.153 513.023
25 25 32,0 150 30,0 -7.0 DN..110408 512.060 513.060
32 25 32,0 170 38,0 -7.0 DN..150608 512.153 513.023
32 32 40,0 170 38,0 -7.0 DN..150608 512.153 513.023
40 25 32,0 200 38,0 -7.0 DN..150608 512.153 513.023
16 16 20,0 100 22,0 -6.0 DN..110408 512.060 513.060
20 20 25,0 125 30,0 -7.0 DN..110408 512.060 513.060
20 20 25,0 125 36,0 -7.0 DN..150608 512.153 513.023
25 25 32,0 150 30,0 -7.0 DN..110408 512.060 513.060
25 25 32,0 150 — -7.0 DN..150608 512.153 513.023
32 25 32,0 170 38,0 -7.0 DN..150608 512.153 513.023
32 32 40,0 170 38,0 -7.0 DN..150608 512.153 513.023
40 25 32,0 200 38,0 -7.0 DN..150608 512.153 513.023
punch
pin
515.018
515.018
515.018
515.018
515.018
515.018
515.018
515.018
515.018
515.018
515.018
515.018
515.018
515.018
515.018
lever
511.060
511.060
511.024
511.060
511.024
511.024
511.024
511.060
511.060
511.024
511.060
511.024
511.024
511.024
511.024
lever
screw
514.118
514.118
514.128
514.118
514.128
514.128
514.128
514.118
514.118
514.128
514.118
514.128
514.128
514.128
514.128
Torx
Plus
10 IP
10 IP
15 IP
10 IP
15 IP
15 IP
15 IP
10 IP
10 IP
15 IP
10 IP
15IP
15 IP
15 IP
15 IP
