S-Style Screw Clamp Toolholders for Positive Inserts
See pages B30–B46
for inserts.
SCLC 95°
order number catalogue number H B F L1 L2
gage
insert
shim
shim
screw
hex
insert
screw
Torx
right hand
3900169
3900172
SCLCR1010E06
SCLCR1212F06
10 10 12,0 70 12,0 CC..060204
12 12 16,0 80 12,0 CC..060204
—
—
— — MS1153 T7
— — MS1153 T7
3900170
3879416
SCLCR1212F09
SCLCR1616H09
12 12 16,0 80 16,0 CC..09T308
—
— — MS1155
16 16 20,0 100 16,0 CC..09T308 SKCP343 SRS3 3.5 mm MS1156
T15
T15
3879417
SCLCR2020K09
20 20 25,0 125 16,0 CC..09T308 SKCP343 SRS3 3.5 mm MS1156 T15
3879414
3879418
SCLCR2020K12
SCLCR2525M12
20 20 25,0 125 20,0 CC..120408 SKCP453 SRS4
25 25 32,0 150 19,8 CC..120408 SKCP453 SRS4
4 mm
4 mm
MS1158
MS1158
T15
T15
left hand
3900171
3900173
SCLCL1010E06
SCLCL1212F06
10 10 12,0 70 12,0 CC..060204
12 12 16,0 80 12,0 CC..060204
—
—
— — MS1153 T7
— — MS1153 T7
3900168
3879411
SCLCL1212F09
SCLCL1616H09
12 12 16,0 80 16,0 CC..09T308
—
— — MS1155
16 16 20,0 100 16,0 CC..09T308 SKCP343 SRS3 3.5 mm MS1156
T15
T15
3879412
SCLCL2020K09
20 20 25,0 125 16,0 CC..09T308 SKCP343 SRS3 3.5 mm MS1156 T15
3879415
3879413
SCLCL2020K12
SCLCL2525M12
20 20 25,0 125 20,0 CC..120408 SKCP453 SRS4
25 25 32,0 150 19,8 CC..120408 SKCP453 SRS4
4 mm
4 mm
MS1158
MS1158
T15
T15
See pages B30–B46
for inserts.
SCDP 45°
order number
catalogue number
H
B
F
L1
L2
gage
insert
insert
screw
Torx
right hand
5094163
SCDPR1212H06
12 12 7,0 100 14,0 CP..060203 MS1153
T7
left hand
5094162
SCDPL1212H06
12 12 7,0 100 14,0 CP..060203 MS1153
T7
