Boring Bar
Catalogue Numbering System
для размещения заказа - zakaz@widiahanita.ru
How Do Catalogue Numbers Work?
Each character in our catalogue number signifies a specific trait of that
product. Use the following key columns and corresponding images
to easily identify which attributes apply.
A32SDCLNL12KC04
A
Bar Type
32
Bar Diameter
S
Bar Length**
D
Insert
Holding Method
C
Insert Shape
A
Steel bar with coolant
S
Steel bar without
coolant
C
Carbide bar
D
DeVibrator bar
with coolant
D
Tunable bar
with coolant
E
Carbide bar
with coolant
B
DeVibrator
H
Interchangeable
head
L
Heavy metal bar
with coolant
Metric:
A two-digit number
indicates the bar
diameter in mm.
If the diameter is
represented by a
one digit number, a
0 (zero) will be used
in front of it.
Example:
8mm = 08
3 =F
3.5 = G
4 =H
4.5 = J
5 =K
5.5 = L
6 =M
6.5 = N
7 =Q
8 =R
10 = S
12 = T
14 = U
16 = V
18 = W
20 = Y
**Used only
when more than
one length is
available or a
special length
is required.
D
C
S
P
A
B
C
D
E
H
K
L
M
O
P
R
S
T
V
W
C54
