S-Style Clamping Boring Bars for Positive Inserts
Carbide Shank with Through Coolant
Carbide shank with
through coolant.
See pages B81–B93
for inserts.
E-STFP 90°
order number
catalogue number
D
D min
F
L1 A aF°
gage
insert
right hand
5093696
E08KSTFPR09A 8 11,0 6,0 124 2,4 -6.0 TP..090204
5093750
E10MSTFPR11A 10 13,0
7,0 152 3,2 -4.0 TP..110204
5093755
E12QSTFPR11
12 16,0
9,0 181 4,8 -2.0 TP..110204
5093759
E16RSTFPR11
16 20,0 11,0 201 5,5 0.0 TP..110204
5093773
E20SSTFPR16
20 25,0 13,0 251 7,1 -2.0 TP..16T308
left hand
5093694
E08KSTFPL09A
8 11,0 6,0 124 2,4 -6.0 TP..090204
5093699
E10MSTFPL11A
10 13,0
7,0 152 3,2 -4.0 TP..110204
5093754
E12QSTFPL11
12 16,0
9,0 181 4,8 -2.0 TP..110204
5093758
E16RSTFPL11
16
20,0
11,0 201 5,5
0.0
TP..110204
5093772
E20SSTFPL16
20 25,0 13,0 251 7,1 -2.0 TP..16T308
insert
screw
MS1933
MS1153
MS1153
MS1153
MS1155
MS1933
MS1153
MS1153
MS1153
MS1155
Torx
T7
T7
T7
T7
T15
T7
T7
T7
T7
T15
