Tunable Boring Bars
Steel Shank • Carbide Shank
для размещения заказа - zakaz@widiahanita.ru
Tunable steel shank with through coolant and front end KM™ clamping unit.
D...TTB-KM • Metric
order number
catalogue number
D L1
CSWS
CS
L12
L1 min
system size
3637636
D40MTTB560KM40
40
520
RP 3/8-19
305
330
KM40
3637637
D50MTTB737KM40
50
697
RP 3/8-19
470
337
KM40
3637638
D60MTTB1000KM40
60
976
RP 3/8-19
686
396
KM40
3642134
D80MTTB1120KM63
80 1060 RP 3/8-19 610
560
KM63
3642135
D100MTTB1330KM63 100 1384 RP 3/8-19 622 695 KM63
NOTE: KM adaptors can be found in the WIDIA™ Tooling Systems Catalogue (A-09-02122EN).
Carbide tunable boring bar with KM™ Quick Change connection.
G-KM-TTB • Metric
order number
catalogue number
D L1
3954298
G50MTTB1026KM40 50 986
3954299
G60MTTB1226KM40
60 1186
3954300
G80MTTB1564KM63
80 1504
3954301
G100MTTB2066KM63 100 1975
NOTE: KM adaptors can be found in the WIDIA™ Tooling Systems Catalogue (A-09-02122EN).
CS
RP 3/8-19
RP 3/8-19
RP 3/8-19
RP 3/8-19
CSWS
L12 system size
300 KM40
381 KM40
480 KM63
600 KM63
C84
