Each unique clamping system offers product options to fill your
specific toolholder needs. Find the illustration that fits your application
and navigate to the corresponding page to get the correct solution.
Clamping System M
M
Combined pin/wedge clamp
for negative inserts. An
extremely sturdy clamping
system, specially designed
for interrupted cuts. The tool
is protected by a carbide shim.
MCFN
90°
Page:
C92
MDQN
107,5°
Page:
C96
MSTN
60°
Page:
C100
MCFN
Page: C62
Product Name
Application Illustration
Page Number
MCKN
75°
Page:
C93
MSKN
75°
Page:
C97
MSYN
85°
Page:
C101
MCLN
95°
Page:
C94
MSRN
75°
Page:
C98
MTFN
90°
Page:
C102
MDJN
93°
Page:
C95
MSSN
45°
Page:
C99
MTGN
90°
Page:
C103
P-Style Clamping
P
Lever-type clamping system
for negative indexable inserts
with hole to DIN 4988 and
positive round inserts more
than 20mm in diameter. Inserts
with one- and two-side chip
control geometries have
positive rakes from 6° to 18°.
Advantages of this system are
fast insert changes and no
interference with chip flow.
PCLN
95°
Page:
C104
PSKN
75°
Page:
C105
