S-Style Screw Clamp Cartridges for Positive Inserts
See pages B68–B80
for inserts.
SSKC 75°
order number
catalogue number
D min
F
L1 aF° aP°
gage
insert
right hand
3871192
SSKCR10CA09
40 14,0 50 -4.3 -2.5 SC..09T308/SC..3252
3871191
SSKCR12CA12
50
20,0 55 -3.0 0.0
SC..120408/SC..432
3871190
SSKCR16CA12
60
25,0 63 -3.0 0.0
SC..120408/SC..432
left hand
3871243
SSKCL12CA12
50
20,0 55 -3.0 0.0
SC..120408/SC..432
Spare Parts
D min
40
50
60
insert
screw
MS1155
MS1157
MS1157
Torx
T15
T15
T15
radial
adjusting
screw
KUAM28
KUAM23
KUAM25
hex
2 mm
2.5 mm
2.5 mm
axial
adjusting
screw
KUAM30
KUAM31
KUAM32
mounting
screw
191.405
191.406
191.407
hex
4 mm
4 mm
5 mm
washer
CSWM 060 050
CSWM 060 050
CSWM 080 050
C120
