Small Hole Boring Bars for Turning
Clamping System S • Steel Stepped
CSBM • STEPPED
gage
insert
order number catalogue number KRI D D min D2 F L1 L4 A aF° aP° insert screw Torx
right hand
2831606
CSBM5210250R 90 10,00 5,94 5,16 3,10 70,00 25,72 1,02 0.0° 5.0° CD..S4T002 CC11 T6
2831499
CSBM5212250R 90 12,00 5,94 5,16 3,10 70,00 25,40 1,02 0.0° 5.0° CD..S4T002 CC11 T6
2831477
2831462
CSBM6412190R
CSBM6412320R
90 12,00 7,42 6,60 3,86 70,00 19,05 1,02 0.0° 5.0° CD..S4T002 CC11
90 12,00 7,42 6,60 3,86 70,00 31,75 1,02 0.0° 5.0° CD..S4T002 CC11
T6
T6
2831661
CSBM4510125R 95 10,00 5,18 4,57 5,18 69,85 12,70 1,02 0.0° 5.0° CD..S4T002 CC09 T6
2831639
2831615
CSBM5210125R
CSBM5210255R
95 10,00 5,78 5,16 2,95 70,00 12,30 1,02 0.0° 5.0° CD..S4T002 CC09 T6
95 10,00 5,78 5,16 5,78 69,85 24,96 1,02 0.0° 5.0° CD..S4T002 CC11 T6
2831595
2831548
2831512
CSBM6410195R
CSBM4512125R
CSBM5212255R
95 10,00 7,24 6,60 3,68 70,00 19,05 1,02 0.0° 5.0° CD..S4T002 CC11
95 12,00 5,18 4,57 2,64 69,85 12,70 1,02 0.0° 5.0° CD..S4T002 CC09
95 12,00 5,78 5,16 2,95 70,00 25,40 1,02 0.0° 5.0° CD..S4T002 CC09
T6
T6
T6
2831490
2831468
CSBM6412195R
CSBM6412325R
95 12,00 7,24 6,60 3,68 70,00 19,05 1,02 0.0° 5.0° CD..S4T002 CC11 T6
95 12,00 7,24 6,60 3,68 70,00 31,75 1,02 0.0° 5.0° CD..S4T002 CC11 T6
left hand
2831656
2831588
CSBM4510125L
CSBM6410195L
95 10,00 5,18 4,57 2,64 70,00 12,70 1,02 0.0° 5.0° CD..S4T002 CC09
95 10,00 7,24 6,60 3,68 70,00 19,05 1,02 0.0° 5.0° CD..S4T002 CC11
T6
T6
3890853
3890854
CSBM4512125L
CSBM4512255L
95 12,00 5,18 4,57 2,64 69,85 12,70 1,02 0.0° 5.0° CD..S4T002 CC09
95 12,00 5,18 4,57 2,64 69,85 25,40 1,02 0.0° 5.0° CD..S4T002 CC09
T6
T6
2831528
CSBM5212125L 95 12,00 5,78 5,16 2,95 70,00 12,70 1,02 0.0° 5.0° CD..S4T002 CC11 T6
2831483
3890855
CSBM6412195L
CSBM6412325L
95 12,00 7,24 6,60 3,68 70,00 19,05 1,02 0.0° 5.0° CD..S4T002 CC11
95 12,00 7,24 6,60 3,68 70,00 31,75 1,02 0.0° 5.0° CD..S4T002 CC11
T6
T6
