Small Hole Boring Bars for Turning
Clamping System S • Carbide
QCBM
gage
insert
order number catalogue number KRI D D min F
L1
A aF° aP°
insert
screw Torx
right hand
3854445
QCBM102540R
90 10,00 11,15 5,79 254,00 3,20 0.0° 5.0° TP..110202 QC21
T9
2824776
QCBM102545R
95 10,00 11,15 5,79 254,00 3,20 0.0° 5.0° TP..110202 QC21
T9
2824747
QCBM122545R
95 12,00 13,16 6,81 254,00 4,70 0.0° 5.0° TP..110202 QC21
T9
left hand
3896043
QCBM122540L
90 12,00 13,16 6,81 254,00 4,70 0.0° 5.0° TP..110202 QC26
T9
3896044
QCBM122545L
95 12,00 13,16 6,81 254,00 4,70 0.0° 5.0° TP..110202 QC26
T9
Clamping System S • Steel
QSOM
gage insert
order number catalogue number KRI D D min D2 F L1 L4 FS W A aF° aP° insert screw Torx
right hand
2824819
QSOM9516385R 95 16,00 16,51 9,50 0,64 95,25 38,10 10,63 10,70 2,03 0.0° 5.0° TP..110202 QC26 T9
D20
