WIDIA™ Victory™ • High-Performance Inserts
Chipbreaker Geometries
Negative Inserts (continued)
UR
Roughing geometry with smooth chip forming and improved coolant flow for increased tool life.
Positive geometry reduces cutting forces and improves depth-of-cut notching resistance. Ideally
suitable for stainless steel applications and for smooth machining of steel.
P
M
K
Corner Radius
S
16,0
8,0
4,0
2,0
1,0
0,5
0,1 0,2 0,4 0,8 1,6
feed rate (mm)
fn
Cutting Edge
Positive Inserts
2
Sharp edge for finish machining. Good chip control with very small chip sections.
High dimensional accuracy and smooth surface finishes. Inserts with .008" corner radius
precision-ground on all sides.
Corner Radius
P
M
K
N
S
H feed rate (mm)
fn
Cutting Edge
41
Preferred for light- to medium-duty machining. Low cutting forces and reduced power
requirements due to positive rake angle. Good chip control over a wide range. Also used
on short-chipping cast iron.
P
M
K
Corner Radius
Cutting Edge
B24
zakaz@widiahanita.ru
www.widiahanita.ru
feed rate (mm)
fn
(continued)
