Quadralock™ •
High-Precision Products for I.D. Applications
Easy access, quick-change toolholders and inserts perform multiple I.D.
applications for maximum productivity with one toolholder.
The unique cutting tip of the Quadralock™ I.D. Quick-Change Tooling System
can be locked in four different positions, enabling operation in both Swiss-style
and conventional machines. Four quick, easy setup steps and guaranteed insert
repeatability within ±0,013mm ensures superior performance.
Quadralock
Quadralock Ultra-Precision Tooling
Features
• Fixed-limit stop for precise and repeatable
cutting edge positioning.
• Tight insert seat pocket ensures secure hold.
• V-slots and limit-stop bolts for increased
indexability.
Boring
Bore holes as small as 0,25mm.
Benets
• Internal coolant supply directly lubricates
cutting edge.
• Ability to rotate tool at 90° increments.
• For all boring, grooving, proling, and
threading applications.
Grooving
Groove in a 2,79mm diameter hole.
Proling
Prole in diameters as small as 1,57mm.
Threading
Thread down to a No. 5; 2,54mm.
D72
