Custom Solutions
Custom Solution Worksheet
для размещения заказа - zakaz@widiahanita.ru
For more than 50 years, WIDIA-CIRCLE™ has offered the most reliable,
highest-quality small hole boring bars available.
Although our extensive product line covers most machining applications,
we understand that a custom solution tool may be required.
Flat Location(s)
Straight Shank-Type Boring Bars
Steel or Carbide
Date
Customer-Specied Dimensions
= O.A.L. (Overall Length) From 3x bar diameter to catalogue length.
= “F” Dimension
0,254mm from basic dimension shown in catalogue triangle insert bars only.
= “A” Dimension
+10° to -10° triangle insert bars only.
= Flat Location(s)
1 Flat — no charge (see illustration above).
Special Instructions
(please make any necessary notes
or sketches in the box at right)
Closest Catalogue Standard
Customer
Distributor
Shipping Requirements
Attention Distributors: Use this worksheet
to collect information for your customer.
UGround
UNext Day Air
U2nd Day Air
U3rd Day Air
D90
