WMT™ Turning, Grooving, Cut-Off, and Proling
Choosing the Correct WMT Tooling
3 Select your toolholder based on
the application:
A Choose the appropriate width
“W” required for the application.
B Choose the shortest cutting depth
“CD” dimension for increased
tool rigidity.
C Select the largest toolholder
shank “H” and “B” dimensions
for maximum rigidity.
B
A
C
C AB
C
application
O.D. Grooving and Cut-Off
Face Grooving
I.D. Grooving
Plunge and Turn
conventional
toolholders
pages E30–E32
modular
blades
page E38
pages E33–E34
page E35
page E39
–
pages E30–E32
page E38
