TopGroove™
Holder Identication System
TopGroove™
Catalogue Numbering System
N
Insert
Holding
Method
N—
TopGroove*
S
Insert
Mounting
Location
End mount
EE
*Proprietary
standard only.
Side mount
Offset
SS
Side mount
No offset
for swiss
machining
AASS
NSR2525M4
R
Hand
of Tool
2525 M
Drop Shank Tool Length
Head Size
Shank height
and width in mm
and holder length
according to ISO
standard.
DH
DH = Drop Head
L1 ISO
32
40
50
60
70
80
90
100
110
125
140
150
160
170
180
200
250
300
350
400
450
500
Special
Length
A
B
C
D
E
F
G
H
I
J
K
L
M
N
P
Q
R
S
T
U
V
W
Y
X
4
Insert
Size
W1
Qualied
Surface and
Length
insert
size W1
2 3,81mm
3 4,95mm
4 6,98mm
5 9,65mm
6 9,73mm
8 11,13mm
NRR undercut
End mount
R LL
Q—
qualified metric holder
Side mount
RL
back clearance
NOTE: Holders are designed to locate
insert inclined to 3° to provide back
clearance down open side.
