TopGroove™
How to Place Custom Order
для размещения заказа - zakaz@widiahanita.ru
TopGroove™ Inserts: The Best Platform for Customisation
All TopGroove custom order inserts benefit from the superior rigidity of our
TopGroove toolholder and clamping system. For added productivity, most
custom orders can be incorporated into the double-ended inserts.
Custom orders start with proven WIDIA™ carbide grade technology as the
basis for optimising tool performance. Positive top rake angles are also
available in most inserts.
State-of-the-art CAD enables rapid development of your custom insert
design. For convenience, a concept drawing is always available to facilitate
engineering development of an insert.
There are limitless variations of the flat-top TopGroove design. Additionally,
chip control in the most common styles enables true optimisation and
productivity. WIDIA offers NB- and NBD-style insert blanks as well.
These blanks can be end-form ground in your own shop.
Whatever your special grooving requirements may be, WIDIA can
provide an effective solution. We have the technical expertise, resources,
and commitment to help you develop insert designs that satisfy your
metalcutting application demands.
top rake
top rake (std. 5°)
style A
style B1
angle 3
style B2
angle 1
style B3
style B4
angle 1
style D
angle 2
style F
angle 1
(full radius = 1/2 W)
(full radius = 1/2 W)
NOTE: Common styles are shown here in right-hand versions. Left-hand versions are also available.
style C1
angle 1
style G
angle 1
angle 2
angle 2
(full radius = 1/2 W)
E80
