Separator™
Insert Selection System
для размещения заказа - zakaz@widiahanita.ru
1 Choose the application to be performed:
Choose lead angle of insert for application.
R.H. Lead Angle
L.H. Lead Angle
R.H. Lead Angle
2 Identify the material to be machined:
Each tool has a material grid marked
with a letter indicating the materials
that can be machined.
3 Select your toolholder based
on the application:
A Choose the appropriate width of insert
required for the application.
B Choose the shortest cutting depth “CD”
dimension for increased tool rigidity.
C Select the largest toolholder shank
“H” and “B” dimensions for maximum
rigidity.
A
B
P Steel
M Stainless Steel
K Cast Iron
N Non-Ferrous
S High-Temp Alloys
H Hardened Materials
C
AB C
C
E110
