TopThread™

Grades and Grade Descriptions

Coatings provide high-speed

capability and are engineered

for nishing to light roughing.

• Reduce cycle times — high speed capability.

• Longer tool life — new multilayer coating

provides better wear resistance.

P Steel

M Stainless Steel

K Cast Iron

N Non-Ferrous

S High-Temp Alloys

H Hardened Materials

Coating

HC-P10

HC-P25

wear

resistance

toughness

Grade Description

An advanced PVD TiAlN coating over a very deformation-resistant unalloyed carbide

substrate. TN6010 is ideal for finishing to general machining of most workpiece

materials at higher speeds. Excellent for machining most steels, stainless steels, cast

irons, non-ferrous materials, and super alloys under stable conditions. It also performs

well in machining hardened and short chipping materials.

An advanced PVD TiAlN-coated grade with a tough, ultra-fine-grain unalloyed

substrate. For general-purpose machining of most steels, stainless steels,

high-temp alloys, titanium, irons, and non-ferrous materials. Speeds may vary

from low to medium and will handle interruptions and high feed rates.

05 10 15 20 25 30 35 40 45

Uncoated carbide for light and medium machining. For cast iron, all non-ferrous

metals, and non-metals. Also capable of machining hardened materials at low

cutting speeds.

HW-K15

• All TopThread inserts are precision-ground to

provide accurate edge location and secure

locking of the insert in the toolholder pocket.

• TopThread inserts can be used in either

toolholders or boring bars.

• All non-cresting-type threading inserts can be

used for either external or internal applications.

All cresting-type inserts are designated

specifically for external or internal use.

• Right-hand TopThread toolholders use

right-hand inserts. Left-hand TopThread

toolholders use left-hand inserts.

• Right-hand TopThread boring bars

use left-hand inserts. Left-hand TopThread

boring bars use right-hand inserts.

• See this page for carbide grade selection

and more technical information.

left-hand insert right-hand insert
