Laydown Threading
Hardware
для размещения заказа - zakaz@widiahanita.ru
Laydown Threading Toolholders
In all cases, the proper shim selection is important.
WIDIA™ toolholders are supplied with a shim for a 1,5° lead angle. Change the shim if your thread
is more than 1° different. For more details on proper shim selections, see pages F100–F101.
insert
shim
insert screw
insert
shim
clamp assembly
shim screw
shim screw
insert size and screw
3ER
3EL
4ER
4EL
Laydown Threading boring bars
2IR
2IL
3IR
3IL
4IR
4IL
insert screw
S-SA3T
S-SA3T
S-SA4T
S-SA4T
S-SN2T
S-SN2T
S-SA3T
S-SA3T
S-SA4T
S-SA4T
shim
SM-YIE3
SM-YI3
SM-YIE4
SM-YI4
—
—
SM-YI3
SM-YIE3
SM-YI4
SM-YIE4
shim screw and washer
S-SY3T
S-SY3T
S-SY4T
S-SY4T
—
—
S-SY3T
S-SY3T
S-SY4T
S-SY4T
SM —
Y
E
3—
Shim
Y-shim for
E — External
iC — 16mm
Laydown
I — Internal
standard inserts
2P
1P
—
1N
2N
3N
clamp assembly
CK-C3
CK-C3
CK-C4
CK-C4
—
—
CK-C3
CK-C3
CK-C4
CK-C4
2N
Shim Angle
2 positive
1 positive
0
1 negative
2 negative
3 negative
F78
