WIDIA™ Milling Inserts
Catalogue Numbering System
для размещения заказа - zakaz@widiahanita.ru
How Do Catalogue Numbers Work?
Each character in our catalogue number signifies a specific trait of
that product. Use the following key columns and corresponding
images to easily identify which attributes apply.
Face Mills • Victory™ M1200 Mini Series
Inserts
HNPJ-GD
HNPJ-HD
n HNPJ-GD
first choice
alternate choice
P
M
K
N
S
H
catalogue number
HNPJ0704ANSNGD
cutting
edges
12
D
13
nHHNPNJ-HPD J0704ANSNGD
L10 S BS R hm
6,80 4,45 1,27 1,20 0,10
H
Insert Shape
N
Insert Clearance
Angle
AA
B
B
C
C
E
HD
L
E
O
F
R
SG
T
W
Special
X Design
N
P
G12
P
Tolerance
Class
J
Geometry and Clamping Type
symbol hole shape of hole chipbreaker
N without
R without
single-sided
F double-sided
A without
M with cylindrical hole single-sided
G double-sided
W
partly cylindrical
without
with hole, 40–60
T
countersink
single-sided
Q
partly cylindrical
without
with hole, 40–60
U double countersink double-sided
B
partly cylindrical
without
with hole, 70–90
H
countersink
single-sided
C
partly cylindrical
without
with hole, 70–90
J double countersink double-sided
X special design
shape of
insert’s section
indexable inserts with
facets/wipers
indexable inserts with corner radii
insert thickness
iC
4,76–10,00
11,11–14,29
15,00–20,64
22,00–31,16
31,75–35,00
tolerances on “iC”
tolerances on “M”
classes J, K, L, M, N (+/–) class U (+/–) classes M & N (+/–) class U (+/–)
0,051
0,076
0,076
0,127
0,076
0,127
0,127
0,203
0,102
0,178
0,152
0,279
0,127
0,254
0,178
0,381
0,152
0,254
0,2
0,381
iC (+/–) M (+/–) T (+/–)
iC (+/–)
A 0,025 0,005 0,025 J 0,05–0,15*
B 0,025 0,005 0,013 K 0,05–0,15*
C 0,025 0,013 0,025 L 0,05–0,15*
D 0,025 0,013 0,013 M 0,05–0,15*
E 0,025 0,025 0,025 N 0,05–0,15*
F
0,013 0,005 0,025
P**
0,038
G 0,025 0,025 0,013
U 0,08–0,25*
H 0,013 0,013 0,025
*See table above for tolerances according to insert size and class.
**WIDIA standard only.
M (+/–)
0,005
0,013
0,025
0,08–0,20*
0,08–0,20*
0,038
0,13–0,30*
T (+/–)
0,025
0,025
0,025
0,013
0,025
0,038
0,013
