Face Mills • Victory™ M1200 Mini Series
Recommended Starting Speeds
(Recommended Starting Speeds [m/min] — continued)
Material
Group
1
2
3
P
4
5
6
1
M2
3
1
K2
3
1
N2
3
1
2
S
3
4
1
H2
3
WP25PM
WP35CM
WS30PM
WP40PM
TN6501
THM-U
395 340 325 545 475 445 – – – 355 310 295 – – – – – –
330 290 240 335 305 275 – – – 300 260 215 – – – – – –
305 260 210 305 275 245 – – – 275 235 190 – – – – – –
270 220 180 230 210 190 – – – 245 205 160 – – – – – –
220 205 180 310 275 250 – – – 205 185 160 – – – – – –
200 150 120 190 160 130 – – – 180 140 110 – – – – – –
245 215 200 245 220 185 270 240 220 235 205 185 – – – – – –
220 190 155 220 190 170 245 215 175 210 180 150 – – – – – –
170 145 115 175 155 140 185 160 125 155 140 110 – – – – – –
275 245 220 355 320 290 – – – – – – – – – – – –
215 190 180 280 250 230 – – – – – – – – – – – –
180 160 145 235 210 190 – – – – – – – – – – – –
– – – – – – – – – – – – 2400 1440 1200 2400 1440 1200
– – – – – – – – – – – – 1640 980 800 1640 980 800
– – – – – – – – – – – – 960 600 480 960 600 480
50 40 30 – – – 55 50 35 50 40 35 – – – – – –
50 40 30 – – – 55 50 35 50 40 35 – – – – – –
60 50 30 – – – 65 55 35 60 50 35 – – – – – –
85 60 40 80 60 40 100 70 50 80 60 40 – – – – – –
145 110 85 – – – – – – – – – – – – – – –
––––––––––––––––––
––––––––––––––––––
NOTE: FIRST choice starting speeds are in bold type.
As the average chip thickness increases, the speed should be decreased.
Recommended Starting Feeds
Recommended Starting Feeds [mm]
Light
Machining
General
Purpose
Heavy
Machining
Insert
Geometry
.F..LDJ
Programmed Feed per Tooth (fz)
as a % of Radial Depth of Cut (ae)
5% 10% 20% 30% 40–100%
0,48 0,89 1,81 0,34 0,64 1,29 0,26 0,48 0,96 0,22 0,42 0,83 0,21 0,38 0,76
.E..LD
0,48 1,38 2,85 0,34 0,99 2,00 0,26 0,74 1,48 0,22 0,64 1,28 0,21 0,59 1,17
.S..GD
.S..HD
0,92 2,35 3,89 0,66 1,67 2,70 0,49 1,23 1,98 0,43 1,07 1,72 0,39 0,98 1,57
0,92 2,35 3,89 0,66 1,67 2,70 0,49 1,23 1,98 0,43 1,07 1,72 0,39 0,98 1,57
NOTE: Use “Light Machining” value as starting feed rate.
Insert
Geometry
.F..LDJ
.E..LD
.S..GD
.S..HD
